mercredi 31 mai 2023

CONDOR LED N32D33A_TP.VST59S.P89

CONDOR LED N32D33A

TP.VST59S.P89

TSUMV59XUS-Z1

DUMP CONDOR LED N32D33A

LG 47LB5610_EAX65391006(1.1)

LG 47LB5610

EAX65391006(1.1)

EAX65391004(1.0)

panele: LC470DUE (fg)(a3)

Tcon: 6870C-0481A

dump

LG 47LB5610_LA B43B+EAX65391006(1.1).rar/file

Tcon: 6870C-0481A

EAX65423801 (2.1)

mardi 30 mai 2023

LG 42LB5610-TC_ LA/B43B EAX65391005(1.0)

LG 42LB5610-TC

LA/B43B EAX65391006(1.1)
LA/B43B EAX65391005(1.0)

alimentation: EAX65423701(2.1)

panel: LC420DUE(fg)(a3)

Tcon: 6870C-0480A

dump

LG 42LB5610-TC.rar/file

DUMP LG 42LB5610 LA-B43B+EAX65391004+1.0.rar/file

LG 42LF5600-TB_LA/LB 55H EAX66242603 (1.0)

LG 42LF5600-TB

LA/LB 55H EAX66242603 (1.0)

Alimentation: LGP3942D-15CH1

panel: HC420DUN-SLHS3-111X
Tcon: 6870C-0480A

dump

LG 42LF5600-TB.rar/file

lundi 22 mai 2023

Here we can show you some factory service mode only for professional Technician .
( Note : Don't disturb any setting during the operation without knowing the proper function )

Samsung and Sony Service mode Based on CV628-B42
CV338-B42 and CV338-A50 Boards
Source 2580
Source 2583
Source 2587

Also other china universal boards service mode:
Menu 1147
Menu 1183
Menu 1185
Menu 1187

COBY
Enter menu, Hi-Lite “audio” then enter 8893 Mode/Source 2580

Dynex
Source/Input 2580
Hold Vol down on TV and hold the (#1) button on remote

Element
Menu 0000 > menu 1147

Haier
Pull up menu, Hi-Lite “audio” then enter 8893.

Hisense
“Parental ” enter 0000 then select
“Clean All ”

Insignia USA
Input 2580 (TV is on)

LG / Zenith
Hold MENU on TV and MENU on remote for 5 to 10 seconds,

Mitsubishi/Mitsui
Menu 123 or Menu 2470 (TV is on)

NEC
While powering ON, hold "MENU" or "INPUT" on TV,

Panasonic
Hold [ VOL-- ] on TV, press and hold menu button on remote.

Philips
Push Menu , select 062596

Polaroid
Hold [VOL--] and [CHANNEL--] or hold [VOL+] and [CHANNEL+]
(TV is on)

Proscan
In customer menu go to setup, select parental control menu,
enter 0000 then select “clear channel list”.

RCA China board
Menu 1147

Sanyo
Hold VOL Down on TV, press and hold #1 button on remote,
VOL will jump to halfway and set shuts off.
Turn back on have 1st time setup screen.

Samsung
Mute 182 power

Samsung (European)
Power off, Info - Menu - Mute - Power,

Seiki
Menu 0000

Sharp
Menu, 1999
Menu, 3481
Menu, 1147
While holding [ VOL– & INPUT ] buttons on TV plug in set when
“K ” appears push (VOL– & CHANNEL-)

Sony
Hold “arrow up” on Remote and push power button on TV (TV
is ON)

Symphony
Source/input 2580

Toshiba
On Menu, select “Installation”, then “ System Information” press
the right arrow button.
(“System Information” will change to “Factory Reset” or
something similar)

Service Toshiba LED

to enter the Service mode
adjust the volume to zero , press the mute twice from the remote and press the menu button on the TV
(fourth button from the bottom and marked p and decree it shares) ..
to exit the menu shut the TV

to enter Click on Oak control of top and bottom of the image , as specified in red

Vestel
Menu 4725 then select "RESET"

Vision Quest
Source / Input 2580

Vizio
menu under “Help” tab is Factory Default enter
0000

Haier LCD
1. Press “MENU/EXIT”;
2. Press”1”+”9” +”9” +”9”;
3. Press “OK”

Panasonic
While pressing [VOLUME ( - )] button of the main unit,
press [INFO] button of the remote control three times
within 2 seconmo

AOC
TV mode adjust volume to zero, press mute key
and press number key 9 8 7 6 .

*TCL* service mode = Press *MENU*, Select *CONTRAST* then enter *9735* or *1950* you will enter *Factory mode* and *Design mode*

Jumper board service menu code

Menu+8896

2
TP.HV320.PB801
service menu code
MENU +1147

3
TR.85.03
service menu code
MENU+1147

4
T.VST59.031 .A81 A8
service menu code
MANU +1147

5
T.V56.031 a8
service menu code
MENU+1147

6
V56U V56J.11.2
service menu code
MENU+1147
INPUT+2580
INPUT+0000

7
VST29.03 All
service menu code
MENU+1147

8
SKR.031
service menu code
MENU+1147

9
SKR. 801
service menu code
MANU +1147

10
T5964.81
service menu code
MENU+1147

11
TELEFUNKEN ALL LCD SERVICES MENU CODES MENU+4725

12
CHINA LCD SERVICES MENU CODE
PRESS MENU BUTTON picture contrast
NOW PRESS 9705

13
VIDEOCON LCD SERVICES MENU CODE
LCD 19"20" MENU+123
LCD 26"32" MENU+SOUNDS POP UP+8532

14
VIDEOCON TV SERVICES MENU CODE
Design mode MENU +0203
SERVICE mode MENU +0323
Design mode MENU +1982
SERVICE mode menu +1947
MENU +1147
MENU +6483

Intercode
99 12 20
200528
020322
200528

15
LG LCD SERVICES MENU CODE
Service Remo lie
1 POWER ONLY
2 IN.STOP
3 IN.START
4 EZ.ADJ
Intercode
0000
7777
0431
8741
8743
8878

* *****************************************************

CL22TR11 MENU + 2513

CL32TR12 MENU + 2513

LCD24E100 MENU + 8202

LCD24E101 MENU + 8202

LCD32CA1S, CA2S, CA3S MENU + 8202

LCD32E200 MENU + 8202

LCD32E200C MENU + 8202

LCD32E200D MENU + 8202

LCD32E210 MENU + 8202

LCD40LF1S MENU + 8202

LED19F300- LED19F300B MENU + 8202

LED24DL1M MENU + 8202

LED24F300 MENU + 8202

LED24F300P MENU + 8202

LED24L2000 MENU + 8202

LED24T01 MENU + 8202

LED24T02 MENU + 8202

LED28F200 MENU + 8202

LED28L2100 MENU + 8202

LED32C02 /B MENU + 8202

LED32F300 MENU + 8202

LED32F310 MENU + 8202

LED32F311 MENU + 8202

LED32F320 MENU + 8202

LED32F321 MENU + 8202

LED32F322/22B MENU + 8202

LED32T01 MENU + 8202

LED32T28GP MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LED40T28GP MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD19W57 MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD2001EU MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD2233EU MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD22V68A MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD22V68EU MENU + BALANCE + 3205 / MENU + BALANCE +1969

LCD22V88 MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD24V78P /AP MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD24V86P MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD24V88AP MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD26V68N MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD26V79 MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD26V88 MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD3233EU MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD32V68UE MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD32V79 MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD32V79H MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD32V88 MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD32V88H MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD32V88M MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD32V88S MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD39V77PK MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD42V68EU MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD42V68PK MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD42V79P MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD42V88GP MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD42V88P MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD42V88PH MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD47P69GP MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD47V88GP MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD50C10P MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD55V88GP MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LED55T29 MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LEDN29K300 MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LEDN29K300N MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LEDN32D20 MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LEDN32D20A MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LEDN32D33 MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LEDN32K160M MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LEDN32K26 MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LEDN32K300M MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LEDN32K310 MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LEDN40D33P MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LEDN40K160P MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LEDN40K160P MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LEDN40K160P1 MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LEDN40K26P MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LEDN40K366X3D MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LEDN42K560R3D MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LEDN42T36R3D MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LHD32K21SEU MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LHD32V79CEU MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LTDN42K26CEU MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LTDN42K310R3D MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LTDN42V79CEU MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LTDN50C10CEU MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LTDN50K310XCEU3D01 MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LTDN55K610XWAU3D MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LTDN55XT770XW3D MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LTDN65K560XW3D MENU + BALANCE + 3205 / MENU + BALANCE + 1969

LCD29E130 MENU + CONTRAST + 1950

LCD39E120 MENU + CONTRAST + 1950

LED39D3000 MENU + CONTRAST + 1950

LED40D000 MENU + CONTRAST + 1950

***************

Konka LED32F3300CE TV menu usine: menu +2008

iris-A700 mode service menu+ 8893

Toshiba Service Menu- menu application timer spegnimento 2766

ugine led tv 24 32 43 factory setting menu 9135

vestel service=menu-4725

reset sharp led-lc70LE735
PRES volume dawn + input bouton
pranche 220volt 3second 5second

tcl menu contrast 9735

1147 menu

MENU 7100

8633 menu

8600 menu

8500 menu

6568 menu

7592 menu

menu 3foit + 2483

8640 menu

6483 menu

menu 4725

3846 menu

3546 menu

9876 menu

7521 menu

0731 menu

6532 menu

7532 menu
